The Cursed L

Creating your own 3D printed movable type printing press can cause some unexpected problems.

Even when everything is built to plan, exported correctly, and sent to the printer, there are still issues. For my project this manifested in printing the letter “l,” which often failed to print completely. Even with the successfully completed l’s there were still irregularities. While the print was functional, I was still curious as to what was going wrong, why the PLA was not adhering to the build plate and why the skirt (which is part of the build plate adhesion process) was intersecting the print. This issue has been a case study in how many ways a print job can fail.

The first issue which was part of build plate adhesion problem was a blob effect. According to Dremel FAQ’s:

“Why is the filament blobbing on the build platform?

This may be the result of a build failure or a poorly constructed file. The building process may have been interrupted by the computer disconnecting, or by removing the SD card/USB flash drive during the building process. Run the Dremel Test Print to verify that your printer is working correctly, allowing the print to finish completely before disconnecting it.”2

But even though there was a blob, it seemed to have started with an adhesion issue which is a common and reoccurring problem throughout this project. Research about this problem  yielded many results, tips and tricks from different sources. According to Autodesk Instructables, poor adhesion could be due to the heat of the build plate which for PLA should be about 60 degrees Celsius.1  Suggestions to help adhesion include using painter’s tape, a layer of Elmer’s glue, and even hairspray!

Other suggestions even included ensuring the extrusion temperature was appropriate. It needs to be hot enough to push out enough plastic and cold enough to solidify and adhere to the build plate. But if it was too hot then it could not cool, not adhere, and ultimately be dragged around. For PLA this temperature should be around 200 degrees Celsius.1

In another source from 3D Printing – StackExchange, a thread titled Reasons for a PLA print not sticking to bed all the sudden? is answered by a user named Trish who mentions factors to keep in mind:

“Have a sufficient surface for the print to stick. A pyramid printed on the tip can’t print properly.

Check the leveling of your bed occasionally and relevel the bed. By removing prints, one can easily unlevel it over time without noticing it.

Clean your print bed from fingerprints and grease every so often. Fats are good separators between the print and the bed. Getting them off with Isopropyl alcohol or other solvents can restore print surfaces in an instant.”3

This is followed by an answer from another user JayCrossler who mentions a time when their printers all had a non-stick issue around the same time and it was “mostly around changes in temperature and humidity – the outside temperature changed inside AC settings/wind-flow, etc.”3

Any one of these were potential solutions to test; however, the next letter that was printed after the first two fails of the letter “l” came out with a new issue which was seemingly under- extrusion. The base printed fine and the letter was completed but there are tiny gaps within the print, leading me to believe it is a case of under extrusion, where the extrusion temperature was too cool making the layer not want to adhere to the previous layer. Or, another likely issue is that after the two failures, the nozzle was still a little clogged.

The next letter after printed better; however, there was a base issue where the skirt was printed into the print itself. Nothing in my settings had changed and I ensured the print was lying flat. Ultimately, I’m not quite sure what is wrong and why there are issues that seemingly come and go. All I can really think of is that it is a print failure that occurs and like other printers, it’s a typical moody printer.

Perhaps we will just have to take the “L.”


BradBuilds. Failed 3D Prints, and How to Fix Them. (n.d.). Autodesk Instructables. https://www.dremel.com/us/en/digilab/3d-printers-faq

Dremel. Frequently Asked Questions. (n.d.). https://www.dremel.com/us/en/digilab/3d-printers-faq

Reasons for a PLA print not sticking to bed all the sudden? (2019 September 6). 3D Printing – StackerExchange. https://3dprinting.stackexchange.com/questions/10980/reasons-for-a-pla-print-not-sticking-to-bed-all-the-sudden

3D Printing the Past (Update)

The FIG project is near completion! This is a project that is aimed at recreating a historic moveable typeface using 3D modeling and printing in connection with a block press to recreate the printing process. The goal is to engage faculty and students in a discussion, where they will be able to recall the steps in the printing process; identify a historic typeface; and discuss how technology can be used to resurrect a typeface.


As the project wraps up, I’d like to share the process.

Working in the Archives and Special Collections Center and having access to numerable examples of different typefaces, I decided to recreate Fraktur one of the oldest typefaces. By researching some different type specimens, my first step was to create an outline of the letters. I printed out a guide and traced the letters making some edits to smooth out shapes and lines, onto paper which I then scanned into the computer.

From there I opened the scan in Photoshop to enhance the contrast of the scan. Using Curves and the black and white eye droppers is a quick way to make the scan into a black and white image while darkening and lightening specific areas. This method is successful when the tracing is clean, no smudging, and crisp lines. Tracing in ink is ideal especially with a superfine tipped marker.

Tracing of the Fraktur letters

Next was to open, or copy and paste, the edited scan in Illustrator. I would suggest opening the document in Illustrator so that you do not have both programs open and running which can cause them to crash. Once in Illustrator you can create a tracing of the edited scan. If all went well with editing the scan in Photoshop then the resulting tracing in Illustrator should yield a nicely rendered set of letters in black and white.
This is an important step because it creates vector shapes. Once you ungroup and delete the unnecessary white space and use the minus function to ensure letters have the appropriate shape cut out so that the O looks like an O and not a black circle. After that, it is time to save the file as an .svg which will then be uploaded to Fusion360.

Fusion360 offers free trials but is free to use for educators and students which is why I selected it for this project. I have also had previous experience using Fusion360 and other Autodesk software which played a part in my decision. In Fusion360, after inserting the .svg and finishing the sketch, select the shape, the letter should highlight, and under the Create tab select Extrude to extrude the shape. Once that is complete, you can add the base by selecting box and adding the box over the letter that has been extruded.

If you traced and scanned the way I did, the letter will be the correct way as opposed to backwards which is what you need. However, do not worry! If you navigate to the underside of your modeling, you will see that the letter is backwards so it’ll all work out in the end.

Once the letter is extruded and the base added, you can select the entire body, right click and hold to select Isolate. Doing this allows you to export the body to an .stl file. If you export without this step, you would export everything in the file. Afterwards, I always do Ctrl z to undo the Isolation.

Computer screen shows DigiLab Slicer program with3D printers in the background of the photoYou can find all exported files in your files within Fusion360. Here you can download all the .stl’s. While it’s tempting to go straight to printing, there is another step! At least there was for me as I was using a Dremel 3D printer. Using Dremel DigiLab Slicer you can open the .stl and set up your print. You’ll select the material, specify the quality of the print along with how much infill, build plate adhesion, and generate supports if your print requires it. There is also a mode to customize your print where you get more into the details of 3D printing. With all your details set, which includes orienting the file on the build plate, an important step that you shouldn’t forget. From there you can Prepare Slice followed by saving the file as a .gcode.

Using a USB drive, I plugged that into the printer and selected my file to print. From there the printer does its steps to orient itself and warm up while you’ll want to cross your fingers to make sure it all comes out okay!


The specs of the project will vary depending on a number of factors that are specific to your project such as the size of the letter itself and the size of the box that serves as the base of the letter. I tested a few before I came to the one that worked the best for myself and this project.

I started off small, which proved to be an issue. It is important to remember that 3D printers can only print so small. Small prints, especially those that rely on details, may lose those details in printing. I decided to increase the size to keep that detail. Furthermore, I realized I would be using these pieces in a workshop and having a larger example would be easier to show as opposed to the small one.

Here are my tests and their specs with the how they printed:

Test 1:

        • Profile: High Speed (34 mm)
        • Infill: 20%
        • Generate Support: Yes
        • Build Plate Adhesion: Yes
        • Status: FAILED
        • Letter: ENTIRE ALPHABET

Test 2:

        • Profile: High Speed (34 mm)
        • Infill: 20%
        • Generate Support: Yes
        • Build Plate Adhesion: Yes
        • Status: SUCCESSFUL
        • Size:
              • Width: .5 inch (VARIES)
              • Length: .34 inches
              • Height: .5 inches
              • Letter Height: .125 inches
        • Letter: ENTIRE ALPHABET

Test 3:

        • Profile: High Speed (34 mm)
        • Infill: 20%
        • Generate Support: No
        • Build Plate Adhesion: Yes
        • Status: SUCCESSFUL
        • Size:
              • Width: .5 inch (VARIES)
              • Length: .34 inches
              • Height: .30 inches
              • Letter Height: .125 inches
        • Letter: ONE LETTER

Test 4:

        • Profile: High Speed (34 mm)
        • Infill: 20%
        • Generate Support: No
        • Build Plate Adhesion: Yes
        • Status: FAILED
        • Size:
              • Width: .5 inch (VARIES)
              • Length: .34 inches
              • Height: .30 inches
              • Letter Height: .125 inches
        • Letter: THREE LETTERS

Test 5:

        • Profile: High Speed (34 mm)
        • Infill: 20%
        • Generate Support: No
        • Build Plate Adhesion: Yes
        • Status: FAILED
        • Size:
              • Width: .5 inch (VARIES)
              • Length: .34 inches
              • Height: .30 inches
              • Letter Height: .125 inches
        • Letter: ONE LETTER (FILLED IN B, HOLES NOT PRESENT)

Test 6:

        • Profile: High Speed (34 mm)
        • Infill: 20%
        • Generate Support: No
        • Build Plate Adhesion: Yes
        • Status: SUCCESSFUL
        • Size:
              • Width: .5 inch (VARIES)
              • Length: .34 inches
              • Height: .30 inches
              • Letter Height: .125 inches
        • Letter: ONE LETTER C

Test 7:

        • Profile: High Speed (34 mm)
        • Infill: 20%
        • Generate Support: No
        • Build Plate Adhesion: Yes
        • Status: FAILED
        • Size:
              • Width: .5 inch (VARIES)
              • Length: .34 inches
              • Height: .30 inches
              • Letter Height: .125 inches
        • Letter: ONE LETTER (FILLED IN B, HOLES NOT PRESENT)

Test 8:

        • Profile: High Speed (34 mm)
        • Infill: 20%
        • Generate Support: No
        • Build Plate Adhesion: Yes
        • Status: SUCCESSFUL
        • Size:
              • Width: .5 inch (VARIES)
              • Length: .5 inches
              • Height: .5 inches
              • Letter Height: . 5 inches
        • Letter: ONE LETTER B (BUILT DIFFERENTLY IN FUSION360)*
            • *Extrude the sketch which already had the holes.

Final:

        • Profile: High Speed (34 mm)
        • Infill: 20%
        • Generate Support: No
        • Build Plate Adhesion: Yes
        • Size:
              • Scale Design: 3.5
              • Width: VARIES
              • Length: 1.75 inches
              • Height: .5 inches
              • Letter Height: .5 inches

3D Printing the Past

A black Speedball black press, a gray inking plate, and a Speedball brayer.

Working in the Archives and Special Collections Center, we showcase historically significant print materials to visiting classes who have made these visits part of their curriculum. Implementing a printing demonstration and an opportunity for students and faculty to get involved with the printing process itself will bring a new form of learning into the space and a new way to engage and appreciate the items before them. A Faculty Innovation, or FIG grant, now makes this possible.

Over the years I have had the pleasure of attending Rare Book School out of the University of Virginia in Charlottesville, Virginia, which proved to be part of my inspiration for this project. Just this past summer I saw a working reproduction of an eighteenth-century press which is typically given the name of Franklin Printing Press since it is believed that Benjamin Franklin used something similar. I saw the metal moveable type that was laid out, how the ink was applied, how the paper was arranged, and the strength needed to press the paper onto the moveable type. The entire process made me wish I could requisition a press to be built, procure trays of moveable type, have ink balls, quality paper, and ink.

But that would require thousands of dollars, so the question became how can I do this without spending that amount of money? How can I make it portable? And how can I share the results with others?

My project was born. I decided to take one the earliest typefaces to bring back to life by using emerging technology of the 21st century. This project utilizes Photoshop and Illustrator from Adobe Creative Campus in connection with Fusion360 and a Dremel 3D40 printer which uses PLA filament. Additionally, this project uses a Speedball Block Press and brayer along with an inking plate. I will be using the Archives and Special Collections blog to share updates, tips and tricks, successes and failures so that the process can be expanded and even improved upon by others interested in creating a similar project.

While this project is aimed at becoming an interactive component to class visits in the Archives and Special Collections Center for faculty and students, I also get to practice and refine my skills in Photoshop, Illustrator, and 3D modeling while learning about the 3D printing process. And ultimately, I get to take my first steps in faculty scholarship and in crafting a unique learning experience for the community.

As part of this grant, I have been asked how this project can be implemented within the curriculum. Metal moveable type and the printing press, even the digital aspects of this project, relate to many different subject areas as I will outline below but can apply to much more.

Typography and Graphic Design
Since typography is focused on learning about letterforms and words as design elements as well as the historical roots which goes back to Gutenberg this project would be an addition to these learning objectives. As would it be to graphic design where students are focused on creative, conceptual, and practical aspects of graphic design and advertising.

Book History (History of Books)
This project will allow exploration into the process of how books were made focusing on the materiality of the book. It will allow further conversations into materials and even marks of book use and ownership.

Ethics
Much like we have plagiarism policies in place today to discourage the stealing and appropriation of someone else’s work as your own, a similar issue was around during the time of the printing press. Printers would merely obtain a copy of a work that is selling well and print it for themselves.

Education
The printing press led to an increase in books and printed items. Those who wanted books no longer had to rely on scriptoriums to hand-copy books and could now obtain them more easily. With a new influx of books being produced at a rapid pace, educational standards improved. More people learned to read and write while laws were created to ensure people received an education.

Ideology
Did you know Hitler banned Fraktur in a 1941 statement? According to the document the font was believed to have Jewish ties and was therefore banned. While this document was most certainly typed on a typewriter, the idea is the same. The printing press allowed people to share their thoughts more freely and spread their ideologies faster.

3D Technology
This project would not be possible without the use of 3D technology of the 21st century. There are many different applications in which 3D technology can be utilized, not just to replicate typefaces to explore printing press and history but to scan and have objects available for viewing digitally. Furthermore, it allows the development of digital skills in a digital realm where there seems to be very few limitations.

Communications
The printing press revolutionized mass communication. Where the world once relied upon oral traditions and the slow pace of a scriptorium, there was now the printing press which could print multiple pages at a time.

These are just a few examples of how this project can be used to start discussions in different subject areas that are part of the curriculum. And when fully developed and operational, the project in connection with displays of items from the archives and special collections that used a similar process when they were initially created will allow visitors to fully appreciate them.

In an increasingly digital world, materiality still has a foothold that can not be replicated. We can read, we can watch videos, but nothing compares to a live demonstration and exploration into the physical process that sparks conversation beyond our primary impressions.

Stay tuned for the next blog update as the project gets underway!
